Galactika & GS Sigma 22 Mechanical Tube 18350

Galactika & GS Sigma 22 Mechanical Tube 18350 Buy this Mechanical Tube powered by 18350 battery from Smo-King, created by Galactika in collaboration with GS Mod. Small, light and suitable for vaping with MTL Atomizers for Electronic Cigarettes. The best E-Cig mechanical tube on the market.

GS SIGMA 22 BY GALACTIKA

We present the new GS Sigma 22 By Galactika Mod, a small mechanical tube, with attention to detail with all the attention you have on the production of Box Mods and Mechanical Tubes without particular protections. This little jewel mounts a single 18350 universal battery that manages to guarantee an excellent cheek vape with any 22mm (mm) electronic cigarette atomizer.

HOW TO USE

    Unscrew the button anticlockwise then insert the 18350 battery
    of known origin, without external lacerations on the sheath
    insulator, with the positive pole upwards.

    Screw the button back in until it stops.

    Screw the atomizer with protruding and fixed pin
    with resistance inside if possible
    not below 0.7 ohm.

    To vape, press the lower button of the mod.


MAINTENANCE:

For brass and copper parts, the surface oxide can be removed
using a cloth and a special additive (sidol)
for the steel pipe there is no need since it does not oxidize.
For correct operation, it is recommended to keep the threads and button clean.
To clean the thread, simply unscrew the button and proceed with cleaning
while for the button you have to perform some steps:

    being a button that works with opposing magnets, it is important with a finger to hold the insulator firmly before unscrewing the sealing grains to prevent the button from jumping off due to the effect of magnetism.
    unscrew the grains using the Allen wrench provided.
    once the button has been removed, always very carefully because of the magnets, proceed with cleaning and removing the surface oxide.

FEATURES

Mechanical tube name: Sigma 22 with serial
Material: brass + copper / 303 stainless steel + copper
Diameter: upper 22 mm - lower diameter 25 mm
Height: without atom: 63 mm - weight 100 gr
